u-blox ZED-F9P User Manual

u-blox ZED-F9P Interface Description - Manual
Advance Information
Constants for CFG-UART1-PARITY
Constant Value Description
NONE 0 No parity bit
ODD 1 Add an odd parity bit
EVEN 2 Add an even parity bit
6.7.25 CFG-UART1INPROT: Input Protocol Configuration of the UART1 Interface
Input protocol enable flags of the UART1 interface.
CFG-UART1INPROT-* Configuration Items
Configuration Item Key ID Type Scale Unit Description
CFG-UART1INPROT-UBX 0x10730001 L - - Flag to indicate if UBX should be an
input protocol on UART1
CFG-UART1INPROT-NMEA 0x10730002 L - - Flag to indicate if NMEA should be an
input protocol on UART1
CFG-UART1INPROT-RTCM3X 0x10730004 L - - Flag to indicate if RTCM3X should be
an input protocol on UART1
6.7.26 CFG-UART1OUTPROT: Output Protocol Configuration of the UART1 Interface
Output protocol enable flags of the UART1 interface.
CFG-UART1OUTPROT-* Configuration Items
Configuration Item Key ID Type Scale Unit Description
CFG-UART1OUTPROT-UBX 0x10740001 L - - Flag to indicate if UBX should be an
output protocol on UART1
CFG-UART1OUTPROT-NMEA 0x10740002 L - - Flag to indicate if NMEA should be an
output protocol on UART1
CFG-UART1OUTPROT-RTCM3X 0x10740004 L - - Flag to indicate if RTCM3X should be
an output protocol on UART1
6.7.27 CFG-UART2: Configuration of the UART2 Interface
Settings needed to configure the UART2 communication interface.
CFG-UART2-* Configuration Items
Configuration Item Key ID Type Scale Unit Description
CFG-UART2-BAUDRATE 0x40530001 U4 - - The baud rate that should be
configured on the UART2
CFG-UART2-STOPBITS 0x20530002 E1 - - Number of stopbits that should be
used on UART2
See Constants for CFG-UART2-STOPBITS below for a list of possible constants for this item.
CFG-UART2-DATABITS 0x20530003 E1 - - Number of databits that should be
used on UART2
See Constants for CFG-UART2-DATABITS below for a list of possible constants for this item.
CFG-UART2-PARITY 0x20530004 E1 - - Parity mode that should be used on
UART2
See Constants for CFG-UART2-PARITY below for a list of possible constants for this item.
CFG-UART2-ENABLED 0x10530005 L - - Flag to indicate if the UART2 should
be enabled
UBX-18010854 - R04 Advance Information Page 228 of 259

u-blox ZED-F9P Specifications

General

GNSS	GPS, GLONASS, Galileo, BeiDou, QZSS, SBAS
Concurrent GNSS	4
RTK	Yes
Velocity Accuracy	0.05 m/s
Time Pulse Accuracy	30 ns
Operating Temperature	-40°C to +85°C
Supply Voltage	2.7 V to 3.6 V
Channels	184
Frequency Bands	L1, L2
Dimensions	22 mm x 17 mm x 2.4 mm
Interfaces	UART, SPI, I2C
