u-blox ZED-F9P User Manual

u-blox ZED-F9P Interface Description - Manual
Advance Information
Bitfield mode Description continued
Name Description
nStopBits
Number of Stop Bits
00 1 Stop Bit
01 1.5 Stop Bit
10 2 Stop Bit
11 0.5 Stop Bit
Bitfield inProtoMask
This graphic explains the bits of inProtoMask
Name Description
inUbx
UBX protocol
inNmea
NMEA protocol
inRtcm
RTCM2 protocol
inRtcm3
RTCM3 protocol
Bitfield outProtoMask
This graphic explains the bits of outProtoMask
Name Description
outUbx
UBX protocol
outNmea
NMEA protocol
outRtcm3
RTCM3 protocol
UBX-18010854 - R04 Advance Information Page 66 of 259

u-blox ZED-F9P Specifications

General

GNSS	GPS, GLONASS, Galileo, BeiDou, QZSS, SBAS
Concurrent GNSS	4
RTK	Yes
Velocity Accuracy	0.05 m/s
Time Pulse Accuracy	30 ns
Operating Temperature	-40°C to +85°C
Supply Voltage	2.7 V to 3.6 V
Channels	184
Frequency Bands	L1, L2
Dimensions	22 mm x 17 mm x 2.4 mm
Interfaces	UART, SPI, I2C
