D292144.8.fm Quick Start: Running a Job
Chapter 5: Operation 5- 3
6. Set End of Job Options.
• Configure Job Statistics Report/Chart
• Set-up Autosave.
• Configure Bar Code Label printing.
7. Setup Inspection
• Open the 2D Tape Tab on the HMI and turn In-Tape Inspection on.
• Configure inspection with the Keyence software as needed.
Note: To configure vision inspection, see Chapter 4: Setup or consult the Key-
ence User’s Guide which is provided with the 2D Vision System.
8. Setup the Pick Head.
• Ensure correct nozzle is installed for part that will be picked.
• Observe vacuum sensor, adjust nozzle pressure as necessary.
9. Run Job.
• Turn on the Ionizing Fan (optional)
• Close the enclosure doors.
• On the HMI, select the Run Tab then press Run or press the Start button on the
machine.
• Load/unload parts and reels when prompted.
Caution!
V-TEK® Incorporated takes no responsibility for the safety of TM-500 if it is
used for any purpose other than the intended purpose as specified in this
User’s Guide.
