2-6 TM-500 User’s Guide
Ionizing Fan D292144.5.fm
Ionizing Fan
The Omron Ionizing Fan is mounted to the top of the TM-500 Enclosure, directly above the Pick
& Place Bridge. See the manufacturer’s instructions for details.
NOTE: The air regulator for the Ionizing Fan is located inside the back lower enclosure
cabinet. The maximum psi for the Ionizing Fan regulator is 40 psi.
