V-TEK TM-500 - Ethernet Networks

7-12 TM-500 User’s Guide
Ethernet Networks D292144.10.fm
Ethernet Networks
The Ethernet Network for the TM-500 is diagrammed below. Maintenance and Service personnel
are cautioned to review the diagram and instructions that follow thoroughly before disconnecting
any cables
