V-TEK TM-500 - Taper Setup

4-14 TM-500 User’s Guide
Taper Setup D292144.7.fm
Ta p e r S e t u p
1. Take-up Reel
2. Cover Tape Reel
3. Tape Cutter
4. Sprocket & Pinch Wheel
5. Sealer
6. 2D Camera System
7. Tape Track
8. Carrier Tape Motion Sensor
9. Tape Guides
10. Tape Jam Sensors (Embossed on left, Paper on right.)
11. Seal Pressure Control & Gauge
12. Heat Sealer Temperature Controls
13. Low Carrier Tape Detector
14. Carrier Tape Reel
Step 5:
Setup
Output
TA PE R
2
1
14
4
5
12
11
6
7
9
13
10
8
3
