Chapter 2: TM-500 Overview 2- 3
Right Side View
A. Tower Light F. Cover Tape Arm
B. Main Power Switch G. Keyboard Tray
C. Pick & Place Head Assembly H. Air Pressure Regulator
D. Carrier Tape Arm I. Taper Output Module
E. Take-up Arm J. 2D Camera
A
B
E
F
D
I
H
C
J
G
