V-TEK TM-500 - Pick & Place Assembly

2-12 TM-500 User’s Guide
Pick & Place Assembly D292144.5.fm
Pick & Place Assembly
Pick & Place Head
A. Nozzle
B. Nozzle Vacuum Sensor
C. Nozzle Vacuum Filter
Pick & Place Controls
A. Blow-off Air Pressure Gauge & Control
B. Nozzle Vacuum Sensor
A
B
C
AB
