V-TEK TM-500 - Back View

D292144.5.fm Back View
Chapter 2: TM-500 Overview 2- 5
Back View
A. Pick & Place Head Assembly E. Dual Tray Input Module
B. Pick & Place Head Bridge F. Air Pressure Regulator
C. Taper Output Module G. Computer Monitor/HMI
D. Emergency Stops H.Tower Light
A
B
C
G
F
E
D
H
