Enclosure Interior
The interior of the lower cabinet is pictured on this page. The photo above shows the front sec-
tion of the cabinet.
Note: Before opening the lower front, right door, the Input Carrier Tape Reel must be
removed from the Carrier Arm before loosening the bolt to raise the Carrier Arm.
The photo below shows the interior of the back side of the cabinet.
