V-TEK TM-500 - The Taping Module

2-10 TM-500 User’s Guide
The Taping Module D292144.5.fm
The Taping Module
A. Carrier Tape Feed Reel
B. Take-up Reel
C. Cover Tape Reel
D. Sealer
E. Idler Wheel
F. Tape Cutter
G. Drive Sprocket
H. Sealer Shoe Temperature Controls
I. Seal Pressure Control & Gauge
J. 2D Camera (optional)
K. Taper Track
L. Tape Guides
M. Empty Pocket Detector (EPD) not shown. EPD is not used when 2D Camera is enabled.
C
A
I
K
L
B
G
E
D
J
H
F
