Input, Output & Test Options
The TM-500 consists of three areas which require setup when a new job is created: the
Input area, the Testing area and the Output area. Each area may be configured in a vari-
ety of ways, depending on the modules chosen for the TM-500.
The TM-500 must have an Input and Output Module installed to operate. Test Modules
are optional, although the EPD Sensor is included with all machines.
Module options are listed below.
Input Module Options
• Dual Tray Input/Output
• Ionizing Fan
Output Module Options
• Dual Tray Input/Output
Note: Tray Output is only available with Tray Input and 3D Camera options.
• Taper with Heat and PSA Sealer
• Automatic Tape Cutter
Testing Module Options
• Empty Pocket Detection (EPD) Sensor
• 2D Vision for in-tape Mark and Orientation Inspection
Note: This chapter covers the machine setup for the Input and Output Modules and the
EPD Sensor. For setup and configuration instructions for the optional Inspection Modules,
proceed to Chapter 6: Vision/Test Setup & Operation.
