Preparing the Work Area
Work Space Requirements
The TM-500 is an automated pick & place machine which needs to be placed on a flat, stable
surface in a well lit area. It requires a minimum work area of 7’ high x 13.5’ wide x 9‘ deep (2.2m
x 4.1m x 2.7m) to provide sufficient space for the assembled machine when it is fully loaded with
a variety of tape reel sizes. The minimum work area is pictured below.
Minimum
Width = 13.5 feet
Minimum
Height
7 feet
