Vertiv™ | Liebert® STS2/PDU
™
User Manual | Rev. 6 | 10/2017 91
Group 3:
User
Settings
1 SRC1 Fast Undervoltage Setpoint Integer In % of nominal below nominal
2 SRC1 Slow Undervoltage Setpoint Integer In % of nominal below nominal
3 SRC1 Slow Undervoltage Detect Delay Integer In number of lines cycles
4 SRC1 Overvoltage Setpoint Integer In % of nominal above nominal
5 SRC1 Overvoltage Detect Delay Integer In 1/4 lines cycles
6 SRC1 I peak Transfer Setpoint Integer x 10
7 SRC2 Fast Undervoltage Setpoint Integer In % of nominal below nominal
8 SRC2 Slow Undervoltage Setpoint Integer In % of nominal below nominal
9 SRC2 Slow Undervoltage Detect Delay Integer In number of lines cycles
10 SRC2 Overvoltage Setpoint Integer In % of nominal above nominal
11 SRC2 Overvoltage Detect Delay Integer In 1/4 lines cycles
12 SRC2 I peak Transfer Setpoint Integer x 10
13 Max. Transfer Phase Angle Integer In degrees
14 Output Frequency Deviation Integer Freq. in Hz x 10
15 ReTransfer Delay Time Integer In seconds
16 Horn Volume Integer Range: 1-10
17 Critical Option Enabling Bitpacked See section 12.1.3.
18 Non-Critical Option Enabling Bitpacked See section 12.1.3.
Group 4:
Event Mask
Settings
1 to 63 Event Mask settings for faults Event Mask See section 12.1.3.
64 to 143 Event Mask settings for alarms Event Mask See section 12.1.3.
Table 16 Group settings and values (continued)
Group Item: Description Value Type Value Notes
