Vertiv™ | Liebert® STS2/PDU
™
User Manual | Rev. 6 | 10/2017 47
Figure 37 Electrical field connections, 800A Liebert STS2/PDU interconnect wiring
PSP11018
Rev. 0
A A
B
B
Neutral Busbar
See Neutral
Busbar Detail
Ground Busbar
See Ground
Busbar Detail
.44 Dia.
(11.2mm)
Typ. 6 Places
See Section B-B
Drawing PSP11019
See Section A-A
Drawing PSP11019
See Section C-C
Drawing PSP11019
C
C
Breaker
Section
STS
Section
Front
LEFT SIDE
Breaker Section
Accent Panels Removed
RIGHT SIDE
STS Section
Accent Panels Removed
Notes
1. Phase and ground busbars are 1/4" thick.
2. Neutral busbar is 1/2" thick.
GROUND BUSBAR DETAIL
NEUTRAL BUSBAR DETAIL
0.56" (14.2mm)
Typical, 6 Places
0.41" (10.3mm)
Typical, 8 Places
1.5"
(38.1mm)
1.5" (38.1mm)
3"
(76.2mm)
3"
(76.2mm)
1.13"
(28.6mm)
1.13" (28.6mm)
2.88"
(73.2mm)
6"
(152.4mm)
12.75" (323.9mm)
1.75"
(44.5mm)
1.75" (44.5mm)
1.75" (44.5mm)
1.75" (44.5mm)
1.5"
(38.1mm)
0.63"
(16mm)
0.63"
(16mm)
