5.0 OUTPUT POWER WIRING
The Liebert STS2/PDU standard model is provided with a circuit breaker for connecting to the load or a remote
distribution cabinet. Other distribution configurations are available.
The three main types of distributions available for the Liebert STS2/PDU are:
•Output Breaker
• Inline Panelboards—two panelboards (84 poles) on 250A units and four panelboards (168 poles) on 400-800A units.
Square D
®
and General Electric panelboards are available to accommodate bolt-in or plug-in breakers.
•SquareD I-Line
®
Panelboard—designed to accommodate up to 10 plug-in breakers from 100A to 250A. Additionally, 300A
to 400A breakers are available on 800A units.
For other optional distribution methods, contact your local Liebert representative or call 1-800-LIEBERT.
The Liebert STS2/PDU distribution may be mounted on either the right or left side at the customer’s option.
Location of output conduit connections is affected by the location of the output cabinet. See
Figures 8, 9, 12, 13, 16 and 17 for wiring a right-side distribution configuration and Figures 10, 11, 14, 15, 18 and 19
for wiring a left-side distribution configuration. See Figures 23 through 44 for wiring.
See Table 6 for wiring the various output options.
5.1 Customer Connections
The customer is responsible for connections from the Liebert STS2/PDU distribution to the connected load,
either directly or through remote distribution cabinets.
Table 6 Distribution configurations
Distribution Type
For Details See
Electrical Output
Field Connections
Output Breaker
250A Figure 23
400-600A Figure 33
800A Figure 35
Inline Panelboards
250A Figure 30
400-800A Figure 31
I-Line (Square D) Figure 32
