Vertiv Liebert STS2 - 13.0 TOUCHSCREEN DISPLAY

Vertiv™ | Liebert® STS2/PDU
™
User Manual | Rev. 6 | 10/2017 86
92 TRANSFER INHIBITED Transfer inhibited. A, E
93 OUTPUT UV Output is under voltage. D, F, A, E
94 HISTORY LOG FULL
Both History Logs have been written and no more history logs can be written
without clearing one of the logs
A, E
96 INPUT 1 OV INPUT Source 1 over voltage A, E
97 INPUT 1 UV INPUT Source 1 under voltage A, E
98 INPUT 2 OV INPUT Source 2 over voltage A, E
99 INPUT 2 UV INPUT Source 2 under voltage A, E
100 LOAD OVERCURRENT Output over current A, E
101 GROUND OVERCURRENT Ground over current A, E
102 NEUTRAL OVERCURRENT Neutral over current A, E
103 LOAD VOLTAGE THD Voltage THD has exceeded the set limit A, E
104 INPUT 1 CB6 OPEN Source 1 input Circuit Breaker 6 is open A, E
105 INPUT 2 CB7 OPEN Source 2 Input Circuit Breaker 7 is open A, E
106 INPUT 1 OF/UF Source 1 over frequency/under frequency A, E
107 INPUT 2 OF/UF Source 2 over frequency/under frequency A, E
120
121
122
123
124
125
126
127
INPUT CONTACT #1
INPUT CONTACT #2
INPUT CONTACT #3
INPUT CONTACT #4
INPUT CONTACT #5
INPUT CONTACT #6
INPUT CONTACT #7
INPUT CONTACT #8
Input Contact # x is an optional alarm input. The alarm name can be
programmed with an alarm name from the Input Contactor Isolator settings
option under the Comm Options. See Configuring the Input Contact Isolator
Settings on page 107. The alarm is sent to Monitor DSP. The LCD logs the alarm
with the programmed name. Monitor DSP logs it with the generic name which is
how it is reported to the SVT query.
A, E
128 CONFIG MODIFIED A setpoint configuration has changed.
E
129 PASSWORD CHANGED The password for touchscreen access has been modified and saved.
E
130 TIME REPROGRAMMED The system’s time has been reset and saved.
E
131 DATE REPROGRAMMED The system’s date has been reset and saved.
E
132 EVENT LOG CLEARED The event log has been erased.
E
133 HIST LOGS CLEARED Both History Logs have been erased.
E
134 XFER COUNT CLEARED Transfer counter reset to 0 E
135 KWH COUNT CLEARED KW-Hrs counter reset to 0 E
Table 13 Event messages (continued)
ID Alarm Message Description/Cause Action
