Industrial 1.6L Engine Cooling 2-3
Engine Cooling System Specifications
Application Metric English
1.6L (w/o radiator) 3.3 liters 3.5 quarts
1.6L (w/radiator) 9.5 liters 10 quarts
Engine Cooling - 1.6L
Specifications
Fastener Tightening Specifications
Application N•m lb ft lb in
Coolant Temperature Sensor 20 14
Drain Cock to Radiator 18 13
Fan Blade to Pulley Bolts 15-18 10-13
Fan Guard Mounting Bolts 16-20 12-15 12-15
Fan Housing Mounting Bolts 16-20 12-15
All Hose Clamps 2.5 22
Radiator Mounting Bracket Bolts 25 18
Water Pump to Engine Block Mounting Bolts 8 6
Thermostat Housing to Cylinder Head Bolts 10 7
Generator Upper Bracket Mounting Bolt 20 15
Generator Lower Bracket Mounting Bolt 35 26
