0-4 General Information Industrial 1.6L
Fraction (in) Decimal (in) Metric (mm)
33/64 0.515625 13.09687
17/32 0.53125 13.49375
35/64 0.546875 13.89062
9/16 0.5625 14.2875
37/64 0.578125 14.68437
19/32 0.59375 15.08125
39/64 0.609375 15.47812
5/8 0.625 15.875
41/64 0.640625 16.27187
21/32 0.65625 16.66875
43/64 0.671875 17.06562
11/16 0.6875 17.4625
45/64 0.703125 17.85937
23/32 0.71875 18.25625
47/64 0.734375 18.65312
3/4 0.75 19.05
49/64 0.765625 19.44687
25/32 0.78125 19.84375
51/64 0.796875 20.24062
3/16 0.8125 20.6375
53/64 0.828125 21.03437
27/32 0.84375 21.43125
55/64 0.859375 21.82812
7/8 0.875 22.225
57/64 0.890625 22.62187
29/32 0.90625 23.01875
59/64 0.921875 23.41562
15/16 0.9375 23.8125
61/64 0.953125 24.20937
31/32 0.96875 24.60625
63/64 0.984375 25.00312
1 1.0 25.4
Equivalents - Decimal and Metric (cont’d)
Arrows and Symbols
This service manual uses various symbols in order to
describe different service operations. You may find
some or all of these symbols used in the manual.
196216
Legend
(1) Front of Vehicle
(2) View Detail
(3) Ambient Air Mixed with Another Gas or Indicate
Temperature Change
(4) Motion or Direction
(5) View Angle
(6) Dimension (1:2)
(7) Ambient/Clean Air Flow or Cool Air Flow
(8) Lubrication Point – Oil or Fluid
(9) Task Related
(10) Sectioning (1:3)
(11) Gas Other Than Ambient Air or Hot Air Flow
(12) Lubrication Point – Grease or Jelly
