Vortec 1600 - Fastener Tightening Specifications

1-4 Engine Mechanical Industrial 1.6L
Fastener Tightening Specifications
Specification
Application
Metric
English
Starter to cylinder block
40 N@m
13 lb ft
Drive disc to crankshaft
25 N
@
m
18 lb ft
Exhaust manifold to cylinder head 55
N@m
+ 30º + 15º
1)
106 lb in
Camshaft sensor fastening bolt to camshaft housing
18 N@m
13 lb ft
DIS Ignition Module to camshaft housing carrier
18 N
@
m
13 lb ft
Throttle valve injection housing to intake manifold
10 N@m
89 lb in
Upper part of throttle valve injection housing to throttle
valve injection housing
10 N
@
m
89 lb in
Throttle body to intake manifold
2 N@m
18 lb in
Pressure plate to camshaft housing
8.5 N
@
m
75 lb in
Intake manifold to cylinder head
22 N
@
m
16 lb ft
Alternator to alternator support
1.5 N@m
13 lb in
Alternator to alternator shackle
1.5 N
@
m
13 lb in
Alternator support to cylinder block
25 N@m
18 lb ft
Crankshaft pulse pickup bracket to oil pump
4.5 N
@
m
40 lb in
Wiring harness bracket to intake manifold
2 N@m
18 lb in
Rear toothed belt cover to camshaft housing
16 N@m
12 lb ft
Rear toothed belt cover to oil pump and camshaft housing
2.8 N
@
m
25 lb in
Heat shield to exhaust manifold
50 N@m
37 lb ft
Heat shield sleeves (sparkplugs) to cylinder head
9 N@m
80 lb in
Crankshaft pulse pickup to bracket
35 N@m
26 lb ft
Increment disc to toothed belt drive gear
8.5 N
@
m
75 lb in
Wiring trough to cylinder head
8 N
@
m
71 lb in
Knock sensor to cylinder head
20 N@m
15 lb ft
Specification
Application
Metric
English
Fuel supply and return line to throttle valve guards
15 N
@
m
11 lb ft
Coolant pump to cylinder block
8 N@m
71 lb in
Coolant pipe to cylinder block
20 N
@
m
15 lb ft
Crankshaft bearing cap to cylinder block 50
N@m
+ 45º + 15º
1)
37 lb ft
Alternator shackle to intake manifold
20 N
@
m
15 lb ft
Fan housing to radiator
5 N
@
m
44 lb in
Camshaft housing cover to camshaft housing
8 N@m
71 lb in
Camshaft sprocket to camshaft
45 N
@
m
33 lb ft
Oil drain bolt to oil pan
55 N
@
m
41 lb ft
Oil pressure switch to oil pump
30 N
@
m
22 lb ft
Oil filter to oil pump
15 N@m
11 lb ft
Oil pump to cylinder block
10 N@m
89 lb in
Oil pump cover to oil pump
6 N
@
m
53 lb in
Oil intake pipe to oil pump 8
N@m
1)
71 lb in
Oil intake pipe to cylinder block
8 N@m
71 lb in
Oil baffle plate to oil pan
8 N
@
m
71 lb in
