Vortec 1600 - Component Locator; Engine Electrical Components; Engine Electrical Component Locator Views

Industrial 1.6L Engine Electrical 3-7
80363003
Component Locator
Engine Electrical Components
Engine Electrical Component Locator Views
Name Location Locator View Wiring Diagram
Battery Determined by customer usage and application — N/A
Generator At the RH front of the engine Engine Electrical
Component Locator
Views
Pages 3xx
Ignition Switch Determined by customer usage and application — N/A
Starter Motor At the lower RH side of the engine Engine Electrical
Component Locator
Views
N/A
Starter Solenoid On the starter at the lower RH side of the
engine
Engine Electrical
Component Locator
Views
Pages 3xx
Page 3-4
Page 3-4
