1-16 Engine Mechanical Industrial 1.6L
Crank Drive, Cylinder Block (Continued)
Engine 1.6 L Z 16 SE
Piston Rings Specification
Metric
Specification
(English)
Rectangular compression ring
Height 1.20 mm 0.0472 in
Gap 0.30 – 0.50 mm 0.0118 – 0.0197 in
Vertical play 0.02 – 0.04 mm 0.00079 - 0.00157 in
Tapered compression ring
Height 1.50 mm 0.059 in
Gap 0.30 - 0.50 mm 0.0118 – 0.0197 in
Vertical play 0.04 – 0.06 mm 0.00157 – 0.00236 in
Oil scraper ring
Height 3.00 0.1181 in
Gap 0.40 – 1.40 0.0157 – 0.0551 in
Vertical play 0.01 – 0.03 0.00039 – 0.00118 in
Ring gap distribution
1)
120º 120º
1) Arrange gap of upper coil scraper ring 25 to 50 mm (1 - 2 in.) offset to the left and gap of the lower ring 25 to 50 mm
(1 - 2 in.) offset to the right relative to the gap of the lower intermediate ring.
Engine 1.6 L Z 16 SE
Pistonpin Width
(Metric)
Width
(English)
Length 5.50 mm 0.2165 in
Diameter 17.997 – 18.000 mm 0.7085 – 0.7087 in
Bearing 78.985 - 78.995 mm 3.1096 – 3.1100 in
Clearance
in piston 0.009 – 0.012 mm .00035 – .00047 in
in con-rod 0.0 mm 0.0 in
