SAFETY STANDARDS - INSTALLER'S RESPONSIBILITY
- Incorporate a security feature to prevent unauthorized use.
• The gate operator must be properly grounded and the incoming power voltage must match the voltage
label on the juncon box.
• Install enough external entrapment protecon sensors so that pedestrians are protected from
entrapment in both direcons of the gate travel and all hazard areas and possible pinch points are
fully protected. Review the informaon found in “External Entrapment Protecon Sensors” on page
25 and “UL 325 Compliant Sensors” on page 29.
• Install the supplied WARNING signs on the inside and outside of the gate so they are clearly visible
from both sides of the gate. Installing the signs is a requirement for UL 325 compliance.
• Connect radio and other remote access (non-reseng controls) to the RADIO OPTIONS terminals.
• Open and close the gate to conrm that it was properly installed and to ensure reduced risk of
entrapment. Verify the clearance between the gate and adjacent structures per UL 325 Safety
Standards. Have a qualied gate technician test the gate monthly.
• When you complete the installaon, show the end user how to:
- Remove the cover. Turn the power o and on to demonstrate relearn limits aer DC/AC cycles.
- Turn the DC power switch o, which disengages the motor, and manually push the gate.
- Use the Stop Buon located on the side of the control box. It can be accessed through a hole in the
cove r.
Gate operator instrucons must be
given to the owner per UL 325 Safety
Standards.
