Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023
9
INTRODUCING KINETIC DC
Introducing Kinec DC
Thank you for purchasing our premium Kinec DC™ slide gate operator. At Wallace Perimeter Security,
we pride ourselves on quality. Our new line electromechanical gate operators include a number of
unparalleled user benets:
Robust - The components on the SmartDC Controller™ are protected by opto-isolators which shield them
from power surges and lightning strikes.
Power - The SmartDC Controller provides variable speed control to a powerful, connuous duty 24V DC
motor which drives the gearbox. The electronics, motor and gear box are rated to operate in temperatures
that range from -13°F to 158°F (-25°C to 70°C). Kinec DC 15W [Kinec 1] is rated for gates up to 30 feet
long and 1,500 pounds (12m and 682kg). Kinec DC 10FW [Kinec 2] is rated for gates up to 30 and
1,000lbs (12m and 454kg). Solar opons are available for both models.
Finesse - A variable rate of gate acceleraon and deceleraon, dependent upon gate weight and length,
assures very smooth handling.
UPS backup and Solar ready - Two 12V, 8 amp hour (Ah) baeries will provide a fully funconal gate
operator (up to 4000/1219m of gate travel) when AC power is unavailable. Four user-selectable UPS
modes are available. 12VDC and 24VDC are available to power accessory controls. An oponal base
extension is required to provide space for the oponal 50Ah baeries which support solar applicaons or
usage during extended power outages.
Intelligent Features: SmartDC Controller™
Menus and User relays - The SmartDC Controller has 43 menu items to allow installer conguraon of gate
funcon and two user relays, which can be congured for 45 dierent funcons.
Independent adjustment for open and close gate speeds - An easy-to-use menu on the SmartDC Controller
allows the installer to vary the open and close speed sengs.
Intelligent Inherent Entrapment Sensor (IES) - Any impediment to gate travel is sensed by the system,
stopping gate movement per UL 325 Safety Standards. The intelligent system monitors gate power then
adapts the IES to trip at an adjustable threshold above normal power.
Improved Liquid Crystal Display (LCD) - A 32-character LCD provides increased readability for programming
and troubleshoong.
USB communicaons port - A direct connecon provides accessibility to download system diagnoscs and
upload system conguraons using the Smart Touch Analyze and Retrieve Tool (S.T.A.R.T.) soware.
S.T.A.R.T. soware and diagnoscs - With S.T.A.R.T. soware loaded on a laptop computer, you can get
the latest soware upgrade and have an invaluable troubleshoong tool for Wallace Perimeter Security
operators. To download this free soware, visit the Nice | Hysecurity website at hps://hysecurity.com/.
