VEHICLE DETECTOR INSTALLATION OPTIONS
Vehicle Detector Installaon Opons
The SmartDC Controller provides a feature-rich interface to four dierent vehicle detector inputs.
HySecurity’s custom HY5B mini-detector module (Figure 30) plugs directly into the SmartDC Controller
Board making eld installaon much faster plus providing a large performance benet. The detector
communicates with the SmartDC Controller microprocessor to achieve the following benets over
common box type detectors:
• Loop frequency is automacally set and monitored by the SmartDC Controller.
• Very low power draw, which is important for maximum UPS capability during a power failure and
for solar operaons.
• Cross-talk between mulple loops is impossible.
• Best operang frequency for each loop is automacally selected.
• Loop frequency and call strength can be reported on the SmartDC Controller display.
• Loop malfuncons are reported and stored by the SmartDC Controller.
• Most detector or loop faults that can occur are reported and presented on the SmartDC Controller
display.
It is not mandatory to use two separate detectors for inner and outer obstrucon detecon, however the
benets in using an addional detector provide second vehicle tailgang detecon, loitering alert, and
selectable non-reversing opons.
Standard box type 11 pin (24 Volt DC
or 24 Volt AC) vehicle detectors may be
connected in the tradional manner as
described in Installing Standard 11-Pin
Box Type Vehicle Detectors.
Figure 30. HY5B Vehicle Detector Module
