SMARTDC CONTROLLER
SmartDC Controller
This secon of the manual contains informaon about the SmartDC Controller board; its inputs for
peripheral connecons and its monitoring capabilies. This secon explains how to:
1� Make connecons on the SmartDC Controller
2� Perform a Preliminary Test of the Components
3� Connect Vehicle Detectors
4� Connect Accessory Devices
• Entrapment Sensor Connecons
• Access Controls
• Manual Push-Buon Staon
• User Relays
Figure 28. SmartDC Controller
