WIRING AC POWER
Wiring AC Power
Turn o AC power at the source (circuit
breaker panel) before accessing the
wires in the Kinec juncon box.
Follow facility Lock Out/Tag Out
procedures. Make sure both the DC
and AC power switches, on the side of
the Kinec control box, are in the o
posion. See Figure 16.
Wiring of gate operators must conform
to the NEC standards and comply with
all local codes. If you plan to connect
to 230VAC power, read the WARNING in
Figure 16. The voltage selector switch
on the AC Power board must be moved
to the 230V posion or damage to the
operator will occur and void the Limited
Warranty.
Figure 16. Wiring AC Power
