Maintenance2124−1/A1
Winterthur Gas & Diesel Ltd.
2/ 2
14) Use the formula below to calculate the wear rate:
WR =
(D1−D2) x 1000
T1
WR = Wear rate [mm/1000 h]
T1 = Total running hours [h]
D1 = Max. Liner diameter in running surface (points B and below) [mm]
D2 = Liner diameter in non-running surface (point A) [mm]
15) For the maximum permitted inner diameter, refer to 0330−1 Clearance Table,
Cylinder liner.
2015
Measuring Bore Wear
