WinGD X92 - Page 520

Maintenance9403−3/A1
Winterthur Gas & Diesel Ltd.
4/ 11
Tool 94145 Pre-tensioning jack for foundation bolts and
engine stays
1 Piston 7 Vent screw
2 Back-up ring
O-ring
Sealing ring
8 Adapter piece
3 9 Closing valve
4 Cylinder
5 Back-up ring
O-ring
Sealing ring
6
94145−KJ K
it with back-up and O-rings
for pre-tensioning J
ack
94145−KJ
9
1
4
8
MAX. STROKE 5 MM
6
5
2
3
7
WCH02931
Fig. 7
2015
Hydraulic Pre-tensioning Jacks: Storing, Servicing and Maintenance
