Maintenance9403−5/A1
Winterthur Gas & Diesel Ltd.
6/ 41
94050
94050B
94050C
94050G
94050H
Tool for pressure measurement
for pneumatic elements
1 Pressure gauge 0−100 bar
1 Adapter
1 Pressure gauge 0−10 bar
2 Stop valve
B
WCH02814
H
C
BG
94051
94051A
94051B
94051C
94051D
Tool for pressure measurement
for pneumatic elements
1 Pressure generator 700 bar
1 HP hose
1 1/4” connector
1 1/4” NPT connector
B
A
D
C
WCH00644
94101 1 Inside micrometer Set
(7 pieces with a measuring range
50 mm to 1010 mm), with case
WCH02258
94110 1 Thrust device
for removal and fitting of
main bearing cover
6−12 Cylinder
X = 1064 mm
Mass approx.121 kg
X
WCH03831
Standard Tools
2017−11
