Maintenance

9403−5/A1

Winterthur Gas & Diesel Ltd.

27/ 41

94566A 1 Support

for camshaft assembly,

including clamping nut

X = 925 mm

Y1 = 165 mm

Mass approx. 22.4 kg

016.788/08

Standard Tools

2015
