Maintenance9403−5/A1
Winterthur Gas & Diesel Ltd.
38/ 41
94935C 1 Hose
for set-up of pre-tensioning jacks
Length = 2000 mm
013.621/05
94936 2 Hydraulic jacks
working range 933 kN to 1002 kN
(95 t to 100 t)
005.952/00
94942 1 Hydraulic unit
working pressure max. 2000 bar
013.622/05
Recommended Special Tools
94215 1 Lifting tool
for cylinder cover pre-tensioners
Mass approx.84.8 kg
Including:
94209A 1 Wire rope sling with
hook
94215C 10 Shackle
94215D 10 Hook
94215G 1 Lifting tool
X
1
= 1350 mm
WCH02829
X
1
94215G
94215C/D
94209A
Standard Tools
2017−11
