wsm B2420 - Page 57

GENERAL
B2420, WSM
G-43
PS Plug Wrench
Application
• Use for tightening the plug for ball nut assembling.
9Y1210436GEG0021US0
Bushing Replacing Tool, for 4WD front Axle Bracket (Front)
Application
• Use to press fit the bushing.
9Y1210436GEG0056US0
A 64 mm (2.51 in.) L 22.0 mm dia. (0.87 in. dia.)
B 48 mm (1.89 in.) M 3.2 mm dia. (0.13 in. dia.)
C 36.2 to 36.3 mm (1.425 to 1.429 in.) N 3 mm dia. (0.12 in. dia.)
D 8 mm (0.31 in.) O 12 mm (0.47 in.)
E 13 mm (0.55 in.) P 3 mm (0.12 in.)
F 8 mm (0.31 in.) Q
Pin: 6 mm dia. × 15 mm length
(0.24 in. dia. × 0.59 in. length)
G 33 mm (1.30 in.) R C3: Chamfer 3 mm (0.12 in.)
H 45 mm (1.77 in.) S C3: Chamfer 3 mm (0.12 in.)
I 16 mm (0.63 in.) T R10: 10 mm radius (0.39 in. radius)
J 6 mm (0.24 in.) U C12: Chamfer 12 mm (0.47 in.)
K 12.0 to 12.1 mm dia. (0.472 to 0.476 in. dia.) V C1: Chamfer 1 mm (0.04 in.)
A 120 mm (4.72 in.)
B 74 mm (2.9 in.)
C 10 mm (0.39 in.)
D 16 mm (0.63 in.)
E 20 mm (0.79 in.)
F 40 mm dia. (1.57 in. dia.)
G 80 mm dia. (3.15 in. dia.)
H 55 mm dia. (2.2 in. dia.)
I 50 mm dia. (2.0 in. dia.)
KiSC issued 06, 2012 A
