Xerox ColorQube 9303 Series Service Manual

February 2013
6-242
ColorQube® 9303 Family
dC131
General Procedures/Information
Table 26 CCS NVM ID 620-400 to 620-499
NVM ID NVM Name NVM Description Settings Default
620-400 EXT. Tail Reg. adj
(110.0 mm/sec)
EXT. Tail Reg. adjustment
(110.0 mm/sec)
Range = 0 to 244 122
620-401 EXT. Tail Reg. adj
(146.7 mm/sec)
EXT. Tail Reg. adjustment
(146.7 mm/sec)
Range = 0 to 244 122
620-402 EXT. Tail Reg. adj
(165.0 mm/sec)
EXT. Tail Reg. adjustment
(165.0 mm/sec)
Range = 0 to 244 122
620-403 EXT. Tail Reg. adj
(293.3 mm/sec)
EXT. Tail Reg. adjustment
(293.3 mm/sec)
Range = 0 to 244 122
620-404 EXT. Tail Reg. adj
(220 mm/sec)
EXT. Tail Reg. adjustment (220
mm/sec)
Range = 0 to 244 122
620-405 EXT. Tail Reg. adj
(330 mm/sec)
EXT. Tail Reg. adjustment (330
mm/sec)
Range = 0 to 244 122
620-406 EXT. Tail Reg. adj
(440 mm/sec)
EXT. Tail Reg. adjustment (440
mm/sec)
Range = 0 to 244 122
620-407 EXT. LE. adj (55.0
mm/sec)
EXT. Lead Edge. adjustment
(55.0 mm/sec)
Range = 0 to 244 122
620-408 EXT. LE. adj (73.3
mm/sec)
EXT. Lead Edge. adjustment
(73.3 mm/sec)
Range = 0 to 244 122
620-409 EXT. LE. adj (82.5
mm/sec)
EXT. Lead Edge. adjustment
(82.5 mm/sec)
Range = 0 to 244 122
620-410 EXT. LE. adj
(110.0 mm/sec)
EXT. Lead Edge. adjustment
(110.0 mm/sec)
Range = 0 to 244 122
620-411 EXT. LE. adj
(146.7 mm/sec)
EXT. Lead Edge. adjustment
(146.7 mm/sec)
Range = 0 to 244 122
620-412 EXT. LE. adj
(165.0 mm/sec)
EXT. Lead Edge. adjustment
(165.0 mm/sec)
Range = 0 to 244 122
620-413 EXT. LE. adj
(293.3 mm/sec)
EXT. Lead Edge. adjustment
(293.3 mm/sec)
Range = 0 to 244 122
620-414 EXT. LE. adj (220
mm/sec)
EXT. Lead Edge. adjustment
(220 mm/sec)
Range = 0 to 244 122
620-415 EXT. LE. adj (330
mm/sec)
EXT. Lead Edge. adjustment
(330 mm/sec)
Range = 0 to 244 122
620-416 EXT. LE. adj (440
mm/sec)
EXT. Lead Edge. adjustment
(440 mm/sec)
Range = 0 to 244 122
620-417 CVT FS Offset 1p
Duplex Side2-1
Range = 0 to 240 120
620-418 CVT FS Offset 1p
Duplex Side2-2
Range = 0 to 240 120
620-419 CVT FS Offset 1p
Duplex Side2-3
Range = 0 to 240 120
620-420 CVT FS Offset 1p
Duplex Side2-4
Range = 0 to 240 120
620-421 CVT FS Offset 1p
Duplex Side2-5
Range = 0 to 240 120
620-422 CVT FS Offset 1p
Duplex Side2-6
Range = 0 to 240 120
620-423 CVT FS Offset 1p
Duplex Side2-7
Range = 0 to 240 120
620-424 CVT FS Offset 1p
Duplex Side2-8
Range = 0 to 240 120
620-425 CVT FS Offset 1p
Duplex Side2-9
Range = 0 to 240 120
620-426 1p Duplex Center
Regi position
Range = 0 to 7196 3598
620-427 CIS black level
Avg # lines
CIS black level Average num-
ber of lines
Range = 0 to 3 3
620-428 Target black level
auto adjust
Target for black level auto
adjust
Range = 0 to 255 16
620-429 Target white level
auto adjust
Target for white level auto
adjust
Range = 0 to 1023 820
620-430 Digital Offset
Level
Range = 0 to 1023 512
620-431 Black Level Cor-
rection Value
Range = 0 to 255 128
620-432 White Level Cor-
rection Value
Range = 0 to 255 255
620-433 DIPS white level;
Avg # lines
DIPS white level; the average
number of lines
Range = 0 to 4 4
620-434 white stability adj
start point
white stability adjustment start
point
Range = 0 to 4095 10
620-435 white stability adj
Avg area
white stability adjustment aver-
age area
Range = 0 to 255 217
620-436 white stability adj
Ref value
white stability adjustment Ref-
erence value
Range = 0 to 1023 962
620-437 W-Ref density
correction factor
Range = 100 to 255 158
620-438 Fine adj hilite
WhiteStability
Fine adjustment factor for
highlight at white stability
adjustment
Range = 80 to 120 100
620-439 W-Ref den. corr
factor set value
W-Ref density correction factor
set value
Range = 0 to 255 255
620-440 EXT. Lead Reg.
adj (460 mm/sec)
EXT. Lead Reg. adjustment
(460 mm/sec)
Range = 0 to 244 122
620-441 EXT. Tail Edge.
adj (460 mm/sec)
EXT. Tail Edge. adjustment
(460 mm/sec)
Range = 0 to 244 122
Table 26 CCS NVM ID 620-400 to 620-499
NVM ID NVM Name NVM Description Settings Default
