Xerox ColorQube 9303 Series Service Manual

February 2013
6-265
ColorQube® 9303 Family
dC330
General Procedures/Information
10-017 Exit sensor (15) Exits sensor (15) High/Low
Table 4 Input codes 12
Code Displayed Name Description General
12-075 Punch sensor 2 HVF punch position sensor 2 (Q12-
075).
On = Made
12-076 Punch sensor 3 HVF punch position sensor 3 (Q12-
076).
On = Made
12-077 Entry sensor LCSS and HVF entry sensor (Q12-
077).
On = Made
12-078 Punch sensor LCSS and HVF punch position sen-
sor (Q12-078).
On = Made
12-079 Inserter paper length
sensor 1
HVF inserter paper length sensor 1
(Q12-079) detects the DOF (Direc
-
tion Of Feed) sheet size in inserter
tray.
High = sheet size
detected
12-080 Inserter paper length
sensor 2
HVF inserter paper length sensor 2
(Q12-080) detects the DOF (Direc
-
tion Of Feed) sheet size in inserter
tray.
High = sheet size
detected
12-081 Inserter paper width
sensor 1
HVF inserter paper width sensor
(Q12-081) detects STS (Side To
Side) sheet size in inserter tray.
High = sheet size
detected
12-082 Inserter unit empty
sensor
HVF inserter unit empty sensor
(Q12-082) detects paper present
inserter tray.
High = paper present,
low = no paper
12-083 Inserter LE sensor HVF inserter LE sensor (Q12-083)
detects the LE of the paper.
High = LE detected, low
= LE not detected
12-084 Inserter TE sensor HVF inserter TE sensor (Q12-084)
detects the TE of the paper.
High = TE detected, low
= TE not detected
12-085 Inserter bottom plate
sensor
HVF inserter bottom plate sensor
(Q12-085) detects the bottom plate
in home position.
High = home position,
low = not home
12-086 Buffer position sensor HVF Buffer position sensor (Q12-
086) detects paper.
High = paper present,
low = no paper
12-087 HVF booklet exit sen-
sor
HVF booklet exit sensor (Q12-087)
detects paper exiting the finisher to
enter into booklet maker.
High = paper present,
low = no paper
12-088 Nip home sensor HVF nip home sensor (Q12-088)
detects the position of the buffer
movement tray in descending.
High = Nip home
12-089 BM entry sensor HVF BM entry sensor (Q12-089)
detects paper entry to the booklet
maker.
High = paper present,
low = no paper
Table 3 Input codes 10
Code Displayed Name Description General
12-090 Inserter paper length
sensor 3
HVF BM inserter paper length sen-
sor 3 (Q12-090) detects the DOF
(Direction Of Feed) sheet size in
inserter tray.
High = sheet size
detected
12-091 Nip Split Sensor HVF nip split sensor (Q12-091)
detects the position of the buffer
movement tray in ascending.
High = Nip split home
12-092 Paper Pusher Upper
Sensor
HVF paper pusher upper sensor
(Q12-092) detects if the pusher is
in the upper position.
High = upper position
12-093 Pressing and Support
Encoder Snr
HVF pressing and support encoder
sensor (Q12-093) detects the tim
-
ing for pressing and support motor.
High = made, low = not
detected
12-094 Paper Pusher Lower
Sensor
HVF paper pusher lower sensor
(Q12-094) detects if paper pusher
is in lower position.
High = made, low = not
detected
12-096 Ejector motor encoder
sensor
HVF/LCSS ejector module motor
encoder sensor (Q12-096) detects
the timing for ejector module motor.
High = made, low = not
detected
12-097 Ejector roll motor
encoder sensor
HVF ejector roll motor encoder sen-
sor (Q12-097) detects the timing for
ejector plate motor.
High = made, low = not
detected
12-098 Ejector plate home
sensor
HVF ejector plate home sensor
(Q12-098) detects if ejector plate is
in home position.
High = made, low = not
detected
12-099 Ejector lower paddle
home sensor
HVF ejector lower paddle home
sensor (Q12-099) detects if eject
unit lower paddle is in home posi
-
tion.
High = made, low = not
detected
12-106 Compile exit sensor HVF/LCSS Compile exit sensor
(Q12-106)
On/Off
12-107 Top tray exit sensor HVF/LCSS Top tray exit sensor
(Q12-107)
On/Off
12-114 Punch unit home sen-
sor
HVF Punch unit home sensor
(Q12-114)
On/Off
12-118 Chad bin present sen-
sor
HVF Chad bin present sensor
(Q12-118)
On/Off
12-133 LO staple sensor HVF/LCSS LO staple sensor (Q12-
133)
On/Off
12-134 SELF PRIMING sen-
sor
HVF/LCSS SELF PRIMING sensor
(Q12-134)
On/Off
12-135 Staple home sensor HVF/LCSS Staple home sensor
(Q12-135)
On/Off
Table 4 Input codes 12
Code Displayed Name Description General
