Xerox ColorQube 9303 Series Service Manual

February 2013
6-272
ColorQube® 9303 Family
dC330
General Procedures/Information
12-254 BM Staple Head 1
Motor
Runs the HVF BM staple head 1 motor
(MOT12-254)
On/off. 5 seconds
time out
12-255 BM Back Stop Motor Runs the HVF BM backstop motor
(MOT12-255) to receive, staple, then
crease positions
On/off. 90 seconds
time out
12-256 BM Tamper 1 Motor Runs the HVF BM tamper 1 motor
(MOT12-256)
On/off. 90 seconds
time out
12-258 BM Diverter Solenoid Energizes the HVF BM diverter sole-
noid (SOL12-258)
On/off. 5 seconds
timeout
12-259 BM Stack Hold Sole-
noid
Energizes the HVF BM stack hold
solenoids (SOL12-259) part of back
stop assembly
On/off. 5 seconds
time out
12-260 Inserter Clutch. Energizes the HVF inserter clutch
(CL12-260) to drive the pickup roll
On/off.
12-261 Inserter Motor Runs the HVF inserter motor (MOT12-
261) to drive the inserter rolls
On/off.
12-262 Buffer Motor Runs the HVF Buffer motor (MOT12-
262) to drive the buffer rolls
On/off.
12-263 Bypass Feed Motor Runs the HVF bypass feed motor
(MOT12-263) to drive the feed rolls
On/off.
12-264 Nip Split Motor Runs the HVF nip split motor (MOT12-
264) to activate the buffer movement
tray
On/off.
12-265 Paper Pusher Motor Runs the HVF paper pusher motor
(MOT12-265) to drive the paper
pusher
On/off.
12-266 Curl Suppressor Sole-
noid
Energizes the HVF curl suppressor
solenoid (SOL12-266) to activate the
pressing device
On/off.
12-267 Tri Folder Diverter
Solenoid
Energizes the HVF tri folder diverter
solenoid (SOL12-267) to activate the
tri folder diverter gate to divert paper to
tri fold path
On/off.
12-268 Tri Folder Assist Gate
Solenoid
Energizes the HVF tri folder assist
gate solenoid (SOL12-268) to activate
the tri folder assist gate to assist C fold
into second nip
On/off.
12-269 Clutch Drive Energizes the HVF clutch drive (CL12-
269) to drive tri folding rolls
On/off. 5 seconds
timeout
12-271 BM Flapper Motor Runs the HVF Booklet maker flapper
motor (MOT12-271)
On/off. 90 seconds
timeout
12-273 BM Crease Roll Gate
Motor
Runs the HVF BM crease roll gate
motor (MOT12-273) cycle routine
On/off. 15 seconds
time out
12-274 BM Conveyor Drive
Motor
Runs the HVF BM conveyor drive
motor (MOT12-274)
On/off. 90 seconds
time out
Table 20 Output codes 12
Code Displayed Name Description General
12-275 BM Staple Hd 2 Motor Runs the HVF BM staple head 2 motor
(MOT12-275)
On/off. 5 seconds
time out
12-276 BM Crease Roll Gate
Motor Open
Runs the HVF BM crease roll gate
motor (MOT12-276) to the open posi
-
tion
On/off. 90 seconds
time out
12-300 OCT feed offset motor Runs the OCT feed offset motor
(MOT12-300)
On/off.
12-323 Pressing and Support
Motor
Runs the pressing and support motor
(MOT12-323)
On/off. 90 seconds
timeout.
12-324 PTU LED Energizes the pause to unload LED. On/off
12-325 Inserter Bottom Plate
Sensor
Runs the HVF inserter unit motor to
lower the inserter bottom plate sensor.
On/off. 90 seconds
timeout.
Table 21 Output codes 20
Code Displayed Name Description General
20-002 Diag. LED 30 Red Switches diagnostic LED 30 red On/off
20-003 Diag. LED 30 green Switches diagnostic LED 30 green On/off
20-010 Sngl Tone 0Hz Ln1 Emits single tone 0Hz on line 1 On/off
20-011 Sngl Tone 400Hz Ln1 Emits single tone 400Hz on line 1 On/off
20-012 Sngl Tone 1100Hz Ln1 Emits single tone 1100Hz on line 1 On/off
20-013 Sngl Tone 1300Hz Ln1 Emits single tone 1300Hz on line 1 On/off
20-014 Sngl Tone 1650Hz Ln1 Emits single tone 1650Hz on line 1 On/off
20-015 Sngl Tone 1850Hz Ln1 Emits single tone 1850Hz on line 1 On/off
20-016 Sngl Tone 2100Hz Ln1 Emits single tone 2100Hz on line 1 On/off
20-017 ANSAM Ln1 On/off
20-018 CI Ln1 On/off
20-020 DTMF # Line1 Emits DTMF # on line 1 On/off
20-021 DTMF * Line1 Emits DTMF * on line 1 On/off
20-022 DTMF 0 Line1 Emits DTMF 0 on line 1 On/off
20-023 DTMF 1 Line1 Emits DTMF 1on line 1 On/off
20-024 DTMF 2 Line1 Emits DTMF 2 on line 1 On/off
20-025 DTMF 3 Line1 Emits DTMF 3 on line 1 On/off
20-026 DTMF 4 Line1 Emits DTMF 4 on line 1 On/off
20-027 DTMF 5 Line1 Emits DTMF 5 on line 1 On/off
20-028 DTMF 6 Line1 Emits DTMF 6 on line 1 On/off
20-029 DTMF 7 Line1 Emits DTMF 7 on line 1 On/off
20-030 DTMF 8 Line1 Emits DTMF 8 on line 1 On/off
20-031 DTMF 9 Line1 Emits DTMF 9 on line 1 On/off
20-032 DTMF A Line1 Emits DTMF A on line 1 On/off
20-033 DTMF B Line1 Emits DTMF B on line 1 On/off
20-034 DTMF C Line1 Emits DTMF C on line 1 On/off
Table 20 Output codes 12
Code Displayed Name Description General
