Xerox ColorQube 9303 Series Service Manual

February 2013
6-273
ColorQube® 9303 Family
dC330
General Procedures/Information
20-035 DTMF D Line1 Emits DTMF D on line 1 On/off
20-040 V.21 300 bps Line1 Emits V.21 300 bps on line 1 On/off
20-041 V.27ter 2400 bps Line1 Emits V.27ter 2400 bps on line 1 On/off
20-042 V.27ter 4800 bps Line1 Emits V.27ter 4800 bps on line 1 On/off
20-043 V.29 7200 bps Line1 Emits V.29 7200 bps on line 1 On/off
20-044 V.29 9600 bps Line1 Emits V.29 9600 bps on line 1 On/off
20-045 V.17 7200 bps Line1 Emits V.17 7200 bps on line 1 On/off
20-046 V.17 9600 bps Line1 Emits V.17 9600 bps on line 1 On/off
20-047 V.17 12000 bps Line1 Emits V.17 12000 bps on line 1 On/off
20-048 V.17 14400 bps Line1 Emits V.17 14400 bps on line 1 On/off
20-049 V.34 2400 bps Line1 Emits V.34 2400 bps on line 1 On/off
20-050 V.34 4800 bps Line1 Emits V.34 4800 bps on line 1 On/off
20-051 V.34 7200 bps Line1 Emits V.34 7200 bps on line 1 On/off
20-052 V.34 9600 bps Line1 Emits V.34 9600 bps on line 1 On/off
20-053 V.34 12000 bps Line1 Emits V.34 12000 bps on line 1 On/off
20-054 V.34 14400 bps Line1 Emits V.34 14400 bps on line 1 On/off
20-055 V.34 16800 bps Line1 Emits V.34 16800 bps on line 1 On/off
20-056 V.34 19200 bps Line1 Emits V.34 19200 bps on line 1 On/off
20-057 V.34 21600 bps Line1 Emits V.34 21600 bps on line 1 On/off
20-058 V.34 24000 bps Line1 Emits V.34 24000 bps on line 1 On/off
20-059 V.34 26400 bps Line1 Emits V.34 26400 bps on line 1 On/off
20-060 V.34 28800 bps Line1 Emits V.34 28800 bps on line 1 On/off
20-061 V.34 31200 bps Line1 Emits V.34 31200 bps on line 1 On/off
20-062 V.34 33600 bps Line1 Emits V.34 33600 bps on line 1 On/off
20-070 ISDN mode Loopback Applies a loop back of both B channels to the
network
On/off
20-071 ISDN tst mode info 1 Provides INFO 1 signals on both B channels On/off
20-072 ISDN tst mode info 0 Provides INFO 0 signals on both B channels On/off
20-073 ISDN PH-ACT-REQ Able to initiate activation procedures (PH-
ACTIVATE REQUEST) primitive
On/off
20-074 ISDN LED 10/18 Red Switches ISDN LED 10/18 red On/off
20-075 ISDN LED 10/18 Grn Switches ISDN LED 10/18 green On/off
20-076 ISDN line relay Switches SDN line relay On/off
20-080 Sngl Tone 0Hz Ln2 Emits single tone 0Hz on line 2 On/off
20-081 Sngl Tone 400Hz Ln2 Emits single tone 400Hz on line 2 On/off
20-082 Sngl Tone 1100Hz Ln2 Emits single tone 1100Hz on line 2 On/off
20-083 Sngl Tone 1300Hz Ln2 Emits single tone 1300Hz on line 2 On/off
20-084 Sngl Tone 1650Hz Ln2 Emits single tone 1650Hz on line 2 On/off
20-085 Sngl Tone 1850Hz Ln2 Emits single tone 1850Hz on line 2 On/off
20-086 Sngl Tone 2100Hz Ln2 Emits single tone 2100Hz on line 2 On/off
20-087 ANSAM Ln2 - On/off
Table 21 Output codes 20
Code Displayed Name Description General
20-088 CI Ln2 - On/off
20-090 DTMF # Line2 Emits DTMF # on line 2 On/off
20-091 DTMF * Line2 Emits DTMF * on line 2 On/off
20-092 DTMF 0 Line2 Emits DTMF 0 on line 2 On/off
20-093 DTMF 1 Line2 Emits DTMF 1on line 2 On/off
20-094 DTMF 2 Line2 Emits DTMF 2 on line 2 On/off
20-095 DTMF 3 Line2 Emits DTMF 3 on line 2 On/off
20-096 DTMF 4 Line2 Emits DTMF 4 on line 2 On/off
20-097 DTMF 5 Line2 Emits DTMF 5 on line 2 On/off
20-098 DTMF 6 Line2 Emits DTMF 6 on line 2 On/off
20-099 DTMF 7 Line2 Emits DTMF 7 on line 2 On/off
20-100 DTMF 8 Line2 Emits DTMF 8 on line 2 On/off
20-101 DTMF 9 Line2 Emits DTMF 9 on line 2 On/off
20-102 DTMF A Line2 Emits DTMF A on line 2 On/off
20-103 DTMF B Line2 Emits DTMF B on line 2 On/off
20-104 DTMF C Line2 Emits DTMF C on line 2 On/off
20-105 DTMF D Line2 Emits DTMF D on line 2 On/off
20-110 V.21 300 bps Line2 Emits V.21 300 bps on line 2 On/off
20-111 V.27ter 2400 bps Line2 Emits V.27ter 2400 bps on line 2 On/off
20-112 V.27ter 4800 bps Line2 Emits V.27ter 4800 bps on line 2 On/off
20-113 V.29 7200 bps Line2 Emits V.29 7200 bps on line 2 On/off
20-114 V.29 9600 bps Line2 Emits V.29 9600 bps on line 2 On/off
20-115 V.17 7200 bps Line2 Emits V.17 7200 bps on line 2 On/off
20-116 V.17 9600 bps Line2 Emits V.17 9600 bps on line 2 On/off
20-117 V.17 12000 bps Line2 Emits V.17 12000 bps on line 2 On/off
20-118 V.17 14400 bps Line2 Emits V.17 14400 bps on line 2 On/off
20-119 V.34 2400 bps Line2 Emits V.34 2400 bps on line 2 On/off
20-120 V.34 4800 bps Line2 Emits V.34 4800 bps on line 2 On/off
20-121 V.34 7200 bps Line2 Emits V.34 7200 bps on line 2 On/off
20-122 V.34 9600 bps Line2 Emits V.34 9600 bps on line 2 On/off
20-123 V.34 12000 bps Line2 Emits V.34 12000 bps on line 2 On/off
20-124 V.34 14400 bps Line2 Emits V.34 14400 bps on line 2 On/off
20-125 V.34 16800 bps Line2 Emits V.34 16800 bps on line 2 On/off
20-126 V.34 19200 bps Line2 Emits V.34 19200 bps on line 2 On/off
20-127 V.34 21600 bps Line2 Emits V.34 21600 bps on line 2 On/off
20-128 V.34 24000 bps Line2 Emits V.34 24000 bps on line 2 On/off
20-129 V.34 26400 bps Line2 Emits V.34 26400 bps on line 2 On/off
20-130 V.34 28800 bps Line2 Emits V.34 28800 bps on line 2 On/off
20-131 V.34 31200 bps Line2 Emits V.34 31200 bps on line 2 On/off
20-132 V.34 33600 bps Line2 Emits V.34 33600 bps on line 2 On/off
Table 21 Output codes 20
Code Displayed Name Description General
