Xerox ColorQube 9303 Series Service Manual

February 2013
6-274
ColorQube® 9303 Family
dC330
General Procedures/Information
Table 22 Output codes 42
Code Displayed Name Description General
42-062 Abatement fan Runs the abatement fan On/off
42-063 Enclosure fan Runs the enclosure fan On/off
42-064 Drum fan Runs the drum fan On/off
Table 23 Output codes 62
Code Displayed Name Description General
62-002 Exposure lamp Energizes the exposure lamp On/off. 300 seconds
timeout. Can stop
before timeout
62-023 Carriage move home Moves scanner carriage to home posi-
tion.
On/off. can only be
run independently
of other carriage
move components
62-024 Carriage mv doc size Moves scanner carriage to document
size sensing position
On/off. can only be
run independently
of other carriage
move components
62-025 Carriage Mv CVT Moves scanner carriage to CVT posi-
tion
On/off. can only be
run independently
of other carriage
move components
62-026 Carriage Mv A pos Moves scanner carriage to scan audit
position A
On/off. can only be
run independently
of other carriage
move components
62-027 Carriage Mv B pos Moves scanner carriage to scan audit
position B
On/off. can only be
run independently
of other carriage
move components
62-028 Carriage Mv C pos Moves scanner carriage to scan audit
position C
On/off. can only be
run independently
of other carriage
move components
Table 24 Output codes 70
Code Displayed Name Description General
70-025 3 Tray transport motor Feeds paper to vertical transport of
3TM
On/off. 60 seconds
timeout
Table 25 Output codes 71
Code Displayed Name Description General
71-002 T1 feed / elevate motor Runs the tray 1 feed / elevate motor
(MOT 71-002).
On/off. Linked to
tray 1 home sensor.
Paper tray must be
open when motor is
running. 90 seconds
timeout
Table 26 Output codes 72
Code Displayed Name Description General
72-001 T2 feed / elevate motor Runs the tray 2 feed / elevate motor.
(MOT72-001)
On/off. Linked to
tray 2 home sensor.
Paper tray must be
open when motor is
running. 90 seconds
timeout
Table 27 Output codes 73
Code Displayed Name Description General
73-001 T3 feed motor Runs the tray 3 feed motor (MOT73-
001)
On/off. Linked to
tray 3 home sensor.
Paper tray must be
open when motor is
running. 90 seconds
timeout
73-002 T3 elevate motor Runs the tray 3 elevator motor
(MOT73-002) up.
On/off. Linked to
tray 3 home sensor.
Only run with tray
out. 10 seconds tim
-
eout
Table 28 Output codes 74
Code Displayed Name Description General
74-420 Bypass feed motor Runs the MSI feed motor (MOT74-420)
in the feed direction.
On/off. 2 seconds
timeout
Table 29 Output codes 75
Code Displayed Name Description General
75-018 Tray 5 transport motor Feeds paper to middle door vertical
transport
On = Running
Off = Stop 60 sec-
onds timeout
75-019 Tray 5 elevator motor
up
Runs the tray 5 elevator motor
(MOT75-019) up
On = Running
Off = Stop 10 sec-
onds timeout
