Xerox ColorQube 9303 Series Service Manual

February 2013
6-275
ColorQube® 9303 Family
dC330
General Procedures/Information
75-020 Tray 5 elevator motor
down
Runs the tray 5 elevator motor
(MOT75-019) down
On = Running
Off = Stop 10 sec-
onds timeout
75-117 Tray 5 feed motor Runs the tray 5 feed motor (MOT75-
117) to drive the nudger and feed rolls
On=running
Off = stop. 60 sec-
onds timeout
Table 30 Output codes 82
Code Displayed Name Description General
82-001 Vertical Trans Motor
Fwd (M2)
Runs vertical transport motor M2 for-
ward (MOT82-001)
On/off
82-002 Vertical Trans Motor
Rev (M2)
Runs vertical transport motor M2
reverse (MOT82-001)
On/off
82-003 Horizontal Trans Motor
Fwd (M6)
Runs horizontal transport motor M6 for-
ward (MOT82-003)
On/off
82-004 Horizontal Trans Motor
Rev (M6)
Runs horizontal transport motor M6
reverse (MOT82-003)
On/off
82-005 Horizontal illuminator Energizes the horizontal paper path
illuminator
On/off
82-007 Nip C release solenoid Energizes the nip C release solenoid
(SOL83-007).
On/off
82-008 Nip D solenoid Energizes the nip D solenoid (SOL82-
008)
On/off
Table 31 Output codes 83
Code Displayed Name Description General
83-001 Exit Motor Fwd (M5) Exit motor M5 forward (MOT83-001) On/off
83-002 Exit Motor Rev (M5) Exit motor M5 reverse (MOT83-001) On/off
83-003 Exit illuminator Exit illuminator On/off
83-004 HPP diverter solenoid HPP diverter solenoid On/off
83-006 Exit duplex diverter
solenoid
Exit duplex diverter solenoid On/off
Table 32 Output codes 88
Code Displayed Name Description General
88-008 Reg / Preheat Air
Pumps
Reg / preheat air pumps On/off
Table 33 Output codes 89
Code Displayed Name Description General
89-007 Registration Motor A1 Runs registration motor A1 (MOT89-
007)
On/off
Table 29 Output codes 75
Code Displayed Name Description General
89-008 Registration Motor A2 Runs registration motor A2 (MOT89-
008)
On/off
89-009 Reg / Preheat illumina-
tor
Reg / preheat illuminator On/off
89-011 Nip A: open Nip A: open On/off
89-012 Nip A: narrow Nip A: narrow On/off
89-013 Nip A: medium Nip A: medium On/off
89-014 Nip A: wide Nip A: wide On/off
89-015 Reg / Preheat Hatch
close
Reg / preheat hatch close On/off
89-016 Reg / Preheat Hatch
open
Reg / Preheat hatch open On/off
Table 34 Output codes 91
Code Displayed Name Description General
91-016 IOD scanbar Energizes the IOD scanbar On/off
91-021 Carriage drive select
motor
Runs the carriage drive select motor
(MOT91-021)
CAUTION
Do not run the following codes
together: 91-021, 91-023, 91-031, 91-
032, 91-035, 91-036. Running these
codes at the same time can cause
damage to the machine.
On/off
91-023 HM vertical motion
motor
Runs the HM vertical motion motor
(MOT91-023)
CAUTION
Do not run the following codes
together: 91-021, 91-023, 91-031, 91-
032, 91-035, 91-036. Running these
codes at the same time can cause
damage to the machine.
On/off. Carriage
needs to be parked
prior to running this
test
91-024 Printhead roll adjust
motor 1
Runs the printhead roll adjust motor 1
(MOT91-024)
On/off
91-025 HM horizontal motion
motor
Runs the HM horizontal motion motor
(MOT91-025)
On/off
91-026 Printhead roll adjust
motor 2
Runs the printhead roll adjust motor 2
(MOT91-026)
On/off
91-027 Printhead roll adjust
motor 3
Runs the printhead roll adjust motor 3
(MOT91-027)
On/off
91-028 Printhead roll adjust
motor 4
Runs the printhead roll adjust motor 4
(MOT91-028)
On/off
91-029 Printhead stitch adjust
motor 1
Runs the printhead stitch adjust motor
1 (MOT91-029
On/off
Table 33 Output codes 89
Code Displayed Name Description General
