General Procedures and Information
Phaser 3200MFP / Workcentre PE220 04/07 6-25
SMPS & HVPS
It is the power supply for the entire system. It is assembled as an independent module, so it is
possible to use for common use. It is mounted at back of the machine. Power part is divided by
two independent PBAs - SMPS PBA and HVPS PBA. SMPS PBA supplies the DC power for driv-
ing the system and supplies the AC power to the fuser.
SMPS has two output channels: +5V and +24V. HVPS PBA supplies High voltage to the develop-
er part to make a printing image on the paper. High voltages applied to the MHV, THV, DEV, SUP-
PLY.
SMPS
1. AC Input
- Input Rated Voltage: AC 220V ~ 240V / AC 110V ~ 127V
- Input Voltage fluctuating range: AC 180V ~ 270V / AC 100V ~ 135V
- Rated Frequency: 50/60 Hz
- Frequency fluctuating range: 47 ~ 63 Hz
- Input Current: Under 4.0Arms / 2.5Arms
2. Rated Output Power
3. Consumption Power
Table 3:
NO Items CH1 CH2 Remarks
1 CHANNEL +5V
+24.0V
2 CONNECTOR PIN CON 2
5V PIN: #5pin
GND PIN: #6pin
CON 2
24V PIN: #2, #3, #4
GND PIN: #7pin
Jam cover switch
included
3 Rated Output +5V ± 5%(4.75 ~ 5.25V)
+24V -10%/+15%(21.6V ~
27.6V)
4 Max. Output current 0.8 A 2.5 A
5 Peak Loading current 1.0 A 2.7 A within 1ms Duration
6 RIPPLE NOISE 100mVp-p or less 500mVp-p or less
7 Maximum output 2.5W 36W
8 Peak output 4W 55.2W 1ms
9 Protection for loading
shortage and
overflowing current
Fuse Protection or Shut-
down within 1.5A ~ 3.0A
range.
Fuse Protection or Shut-
down within 3.5A ~ 4.5A
range.
Table 4:
NO Items CH1(+5V) CH2(24V) System
1 Stand-By 0.6 A 1.3 A AVG: 65Wh (PE220)
70Wh (Phaser 3200)
2 Printing 0.8 A 1.9 A AVG: 350Wh (PE220)
400Wh (Phaser 3200)
3 Sleep-Mode 0.5 A 0.3 A AVG: 10Wh (PE220)
12Wh (Phaser 3200)
