General Procedures and Information
6-26 04/07 Phaser 3200MFP / Workcentre PE220
4. Power Cord Length: 1830 +/- 50mm
5. Power Cord Switch: Exist
6. Feature
- Withstand Resistance: 100 or more (at DC 500V)
- Insulating revisiting pressure: Must be no problem within 1 min. (at1000Vac,10mA)
- Leaking Current: under 3.5mA
- Running Current: under 40A PEAK (AT 25 °C (77 °F), COLDSTART)
under 50A PEAK (In other conditions)
- Rising Time: within 2Sec
- FallingTime: over 20ms
- Surge: Ring Wave 6KV-500A (Normal, Common)
7. Environment Conditions
- Operating temperature range: 0 °C ~ 40 °C (32 °F ~ 104 °F)
- Maintaining temperature range: -20 °C ~ 40 °C (68 °F ~ 104 °F)
- Preserving Humidity Condition: 10% ~ 90% RH
- Operating atmospheric pressure range: 1atm
8. EMI Requirement: CISPR, FCC, CE, MIC,
9. Safety Requirement: IEC950 UL1950, CSA950, C-UL, Semko, EK, CB, CCC(CCIB),GOST,
EPA,
HVPS Board
The HVPS board creates the high voltage of THV/MHV/Supply/Dev and supplies them to the de-
velopment system for making best quality printing image. The HVPS part takes the 24V and out-
puts the high voltage such as THV/MHV/Supply/Dev, and the outputted high voltage is supplied
to the toner, OPC cartridge, and transfer roller.
(a) Transfer High Voltage (THV+)
- Input Voltage: 24 V DC +15% / -10% (21.6V~27.6V)
- Out Voltage: +1300KV 1.5% (200 Load)
- Out Voltage Trigger: 6.5
- Input Voltage Variation: +5%
Load Variation: +5%
- Out Voltage Rising Time: 100 ms Max
- Out Voltage Falling Time: 100 ms Max
- Transfer Variation Voltage on Environment Variation: +500 V ~ +5000V
- Control Method on environment: THV-PWM ACTIVE, transfer Active signal, of environment
sensing voltage is input and get feed back current, and recalculate it to resistance.
- Control method on transfer output voltage: It is controlled by changing its duty of THVPWM
Signal as follows. 10% Duty: +500V, 90% Duty: +5000V
