General Procedures and Information
Phaser 3200MFP / Workcentre PE220 04/07 6-49
Phaser 3200 Engine Test Mode
Table 2: Phaser 3200 Engine Test Mode
1st
level
2nd level 3rd level 4th level 5th level
Engine
Test
Diagnostic MTR Fan Sol ETC Motor Test 1 : On, 2 : Off – next test selected
Pick Up Test 1 : On, 2 : Off – next test selected
Main Fan Test 1 : On, 2 : Off – next test selected
SMPS Fan Test 1 : On, 2 : Off – next test selected
LSU LSU ErrorTest 1 : On, 2 : Off – next test selected
LD Test 1 : On, 2 : Off – next test selected
Sensor Feed Sensor Test 1. Check : read the sensor
2. Next : Next Sensor test
Exit Sensor Test 1. Check : read the sensor
2. Next : Next Sensor test
Cover Sensor Test 1. Check : read the sensor
2. Next : Next Sensor test
Empty Sensor Test 1. Check : read the sensor
2. Next : Next Sensor test
Heat Test Therm ADC 170 1 : On, 2 : Off (maintain the fusing temp.)
Therm ADC 160 1 : On, 2 : Off (maintain the fusing temp.)
Therm ADC 150 1 : On, 2 : Off (maintain the fusing temp.)
Therm ADC 140 1 : On, 2 : Off (maintain the fusing temp.)
Therm ADC 130 1 : On, 2 : Off (maintain the fusing temp.)
Therm ADC 125 1 : On, 2 : Off (maintain the fusing temp.)
Therm ADC 120 1 : On, 2 : Off (maintain the fusing temp.)
Therm ADC 115 1 : On, 2 : Off (maintain the fusing temp.)
Therm ADC 110 1 : On, 2 : Off (maintain the fusing temp.)
HVPS Test MHV Test (1300V) 1 : On, 2 : Off
Bias Test (350V) 1 : On, 2 : Off
THV Test (1300V) 1 : On, 2 : Off
THV (-) 1 : On, 2 : Off
Engine Pat-
tern
Stripe Pattern 1: On, 2: Off
White Pattern 1: On, 2: Off
Status Print Engine Print
