Xerox Phaser 3200MFP Service Manual

Status Indicator RAPs
Phaser 3200MFP / Workcentre PE220 04/07 2-27
17B Defective MF DIAL
Description
The MF DIAL is not functioning.
Check and Cause Solution
1. Check that the telephone line cord supplied
with the set is connected to TEL LINE cor-
rectly.
1. If the telephone cord is working and there is
no dial tone, try plugging a normal telephone
into the wall socket. If the telephone is work-
ing, then install a new LIU PBA:
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)
2. Listen for a CLICK sound when a key is
pressed.
Note: Key sound must be set to “on” in GP 3,
User Mode.
2. If you cannot hear the Manual Dial CLICK
sound, the OPE Assembly may be defective.
Check and install a new OPE Assembly, PL
5.0 if necessary.
3. Check the connection of the HARNESS
between the LIU and the Main PBA.
3. Check the Speaker connection and the har-
ness between the LIU and the Main PBA,
Install new parts as necessary:
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)
4. Ensure the speaker is connected correctly. 4. Perform Tech mode, GP 4 - Modem Test.
Check and install new parts as necessary:
• Speaker
- PL 1.0 (Workcentre PE220)
- PL 1.2 (Phaser 3200).
• LIU PBA
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200).
• Main PBA
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200).
Note: Product supports MF DIAL type only.
