Xerox Phaser 3200MFP Service Manual

Status Indicator RAPs
2-28 04/07 Phaser 3200MFP / Workcentre PE220
17C Defective FAX SEND/RECEIVE
Description
FAX SEND/RECEIVE is not functioning.
17D Defective FAX SEND
Description
RECEIVE is functioning, but FAX SEND is not functioning or received data is corrupt.
Check and Cause Solution
1. Check that you can hear a dial tone by
pressing Manual Dial.
1. Check and install a new LIU PBA if neces-
sary:
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)
2. Check that you can hear a RECEIVE tone
when MODEM testing in TECH Mode, GP 4.
2. Check and install a new main PBA if neces-
sary:
Main PBA
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)
Check and Cause Solution
1. Check for NOISE on the line. Press Manual
Dial and listen.
1. If the line is noisy, inform the customer.
2. Check the cable between the set and the
wall socket for damage.
2. Check the telephone line cord.
3. Check that the destination fax machine can
receive forwarded faxes by using a different
sending fax machine (preferably from the
same wall socket).
3. Check and install a new LIU PBA:
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)

Xerox Phaser 3200MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 600 x 600 dpi
First Page Out Time	Less than 10 seconds
Copy Resolution	Up to 600 x 600 dpi
Maximum Copy Count	99 copies
Fax Transmission Speed	33.6 kbps
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0
Memory	32 MB
Operating System Compatibility	Windows, Mac OS
Duplex Printing	Manual
Scan Type	Flatbed
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Media Weight	60 to 163 g/m²
Monthly Duty Cycle	10, 000 pages
Toner Yield	Up to 3, 000 pages
