Xerox Phaser 3200MFP Service Manual

Status Indicator RAPs
Phaser 3200MFP / Workcentre PE220 04/07 2-29
17E Defective FAX RECEIVE (1)
Description
FAX SEND is functioning, but RECEIVE is not functioning or the received data is corrupt.
17F Defective FAX RECEIVE (2)
Description
Received data is corrupted.
Check and Cause Solution
1. Check for NOISE on the line. Press Manual
Dial and listen.
1. If the line is noisy, inform the customer.
2. Use a different fax machine to receive from
the same sender (if possible on the same wall
socket).
2. Check and install a new LIU PBA:
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)
Check and Cause Solution
1. Check for NOISE on the line. Press Manual
Dial and listen.
1. If you can hear a noisy line when using
Manual Dial, replace or repair the telephone
line.
2. Ask sender to send to another fax machine
(if possible connected to the same wall
socket)
2. Check and install new parts as necessary:
• LIU PBA
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)
• Main PBA
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)

Xerox Phaser 3200MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 600 x 600 dpi
First Page Out Time	Less than 10 seconds
Copy Resolution	Up to 600 x 600 dpi
Maximum Copy Count	99 copies
Fax Transmission Speed	33.6 kbps
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0
Memory	32 MB
Operating System Compatibility	Windows, Mac OS
Duplex Printing	Manual
Scan Type	Flatbed
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Media Weight	60 to 163 g/m²
Monthly Duty Cycle	10, 000 pages
Toner Yield	Up to 3, 000 pages
