Xerox Phaser 3200MFP Service Manual

Status Indicator RAPs
2-30 04/07 Phaser 3200MFP / Workcentre PE220
17G Defective FAX RECEIVE (3)
Description
The phone is ringing continuously, but the machine does not answer the call.
17H Defective FAX RECEIVE (4)
Description
Received data is reduced by more than 50% in the printing.
17I Defective Automatic Receiving
Description
The automatic receiving function is not working.
Check and Cause Solution
1. Check that the RECEIVE Mode is set to
FAX MODE.
1. Check and install new parts as necessary:
• LIU PBA
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)
• Main PBA
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)
Check and Cause Solution
Check the FAX status of the forwarding side. This is a problem with the sending fax
machine. Inform the customer.
Check and Cause Solution
1. Check that the RECEIVE Mode is set to
FAX MODE.
1. If the RECEIVE Mode is set to the TEL
MODE, reset it to the FAX MODE.
2. Check and install new parts as necessary:
• LIU PBA
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)
• Main PBA
- PL 1.0 (Workcentre PE220)
- PL 1.1 (Phaser 3200)

Xerox Phaser 3200MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 600 x 600 dpi
First Page Out Time	Less than 10 seconds
Copy Resolution	Up to 600 x 600 dpi
Maximum Copy Count	99 copies
Fax Transmission Speed	33.6 kbps
Standard Paper Capacity	250 sheets
Connectivity	USB 2.0
Memory	32 MB
Operating System Compatibility	Windows, Mac OS
Duplex Printing	Manual
Scan Type	Flatbed
Media Sizes Supported	Letter, Legal, Executive, A4, A5
Media Weight	60 to 163 g/m²
Monthly Duty Cycle	10, 000 pages
Toner Yield	Up to 3, 000 pages
