System diagram
*1. The brake of the helm unit does not function and the steering wheel spins freely. Also, the trouble
code 549 (Incompatible Helm version) appears on the CL5 Display, and steering modes other than the
helm unit cannot be used.
*2. The software must be updated if the CL5 Display is earlier than the 2022 model year. The trouble
code items and warning notifications do not show the latest information.
The part numbers are subject to change without notice. Make sure to confirm the latest part numbers.
15 Pigtail bus wire
6Y8-82521-01 0.3 m (1 ft)
6Y8-82521-11 0.6 m (2 ft)
6Y8-82521-21 0.9 m (3 ft)
6Y8-82521-31 1.8 m (6 ft)
6Y8-82521-41 2.7 m (9 ft)
6Y8-82521-51 3.6 m (12 ft)
16 Conversion harness 6YM-83553-00 0.9 m (3 ft)
17 CL5 Display 6YM-83710-17 No Wi-Fi, *2
18 Tank wire 6YD-8356N-00
19 Fuel tank ā
20 Helm harness (2nd station) 6X9-8258A-A1 0.9 m (3 ft)
21 Digital Electronic Control 6X9-48205-30 2nd station
22 EKS harness 6X9-82716-60
23 2nd helm harness
6X9-8258A-01 5 m (16 ft)
6X9-8258A-11 8 m (26 ft)
6X9-8258A-21 12 m (38 ft)
24 Single (inline) hub 6Y8-81920-11 w/ resistor, 4ā6P, White
25 Resistor cap 6Y8-85371-01 6P, Gray
a. Power port
b. Bus port
c. Device port
A. Main station
B. 2nd station
Ref.
No.
Part name Part No. Remarks
To Next Page
