Yamaha F350B - Installing the Shift Rod and SPS

9-3
Shift rod and SPS
Installing the shift rod and SPS
1. Install:
• Bushing
• Grommet
• Dowel pin
•Bracket
• O-ring
•Shift rod
• Circlip
• Washer
• Bushing
2. Install:
•SPS
a. Fit the protrusion “a” on the SPS “1” into
the slot “b” in the tip of the shift rod “2”, and
then turn the SPS “1” in the direction of the
arrow to install it.
b. Install the shift lever “3”.
New
1
1
3
a
b
2
