Yamaha F350B - Connecting the Communication Cable

4-2
YDIS
Connecting the communication cable
CAN-Line
3. Adapter interface
4. USB cable
5. Multi-hub
2. Adapter cap
2. Adapter cap
1. K and CAN harness
1. K and CAN harness 3. Adapter interface
4. USB cable
5. Multi-hub
6. YDIS CAN conversion
harness
7. 6X9 Digital Electronic Control
7. 6X9 Digital Electronic Control
A
B
1. K and CAN harness
2. Adapter cap
3. Adapter interface
4. USB cable
5. Multi-hub
6. YDIS CAN conversion harness
7. 6X9 Digital Electronic Control
A. When connecting to multi-hub
B. When connecting to 6X9 Digital Elec-
tronic Control
