Yamaha F350B - Assembling the Oil Pump; Checking the Oil Cooler Anode

7-62
Oil cooler and oil pump assembly
Checking the oil cooler anode
1. Check:
• Anode
Eroded (1/2 or more worn out)  Replace.
Adhered grease, oil, or scales  Clean.
Do not apply grease, oil, or paint to the an-
odes.
Assembling the oil pump
1. Install:
• Oil seal “1”
(into the oil pump housing “2”)
TIP:
Install an oil seal halfway into the oil pump
housing, and then install the other oil seal.
2. Install:
• Oil seal “1”
(into the oil pump housing “2”)
A. Worldwide
B. USA and Canada
New
A
3
2
4
1
B
5
2
6
1
Driver rod L3 “3”
90890-06652
Needle bearing attachment “4”
90890-06612
Driveshaft bearing installer “4”
YB-06155
Driver handle (large) “5”
YB-06071
Roller bearing installer/remover
“6”
YB-06432
A. Worldwide
B. USA and Canada
Bearing inner race attachment “3”
90890-06640
Bearing housing bearing/oil seal
installer “4”
YB-06111
New
A
3
1
2
B
4
2
1
